Durable Single Strand Roller Chain

Products

Durable Single Strand Roller Chain

  • Details

Material :

C45 steel,304 stainless steel, 316 stainless steel and 201 stainless steel.

We specialized in producing all kinds of standard chains and special chains, such as A or B series chains, roller chains, driving chains, conveyor chains, hoisting chains, agricultural chains, sprockets, gears, wheels and so on;

Roller ChainWire Mesh Conveyor Chain



Short-Pitch Precision Roller Chain Features & Benefits:


  • Single and multiple standard roller chains are available in many sizes.
  • Double-pitch drive chains available for slower speed drives on long centers.
  • High temperature factory pre-lubrication for long life at high speeds.
  • Stainless steel standard roller chain provides excellent corrosion resistance.
  • Case-hardened pin for maximum wear life.
  • Chain modifications available for special operating conditions.
  • Wide waist sidebars for superior fatigue strength.
  • Armor-cased pins for maximum wear resistance.
  • Pre-stressed after assembly to reduce early break in wear.


Stainless steel properties:


Grade

Composition(%)

Temperature

resisting

Specifications

C

Si

Mn

Ni

Cr

Mo

1Cr13

≤0.15

≤0.6

≤0.6

-

12-14

-

650℃

Normal conveyor use

1Cr17

≤0.15

≤0.6

≤0.6

-

12-18

-

650℃

Normal conveyor use

304M

≤0.06

≤1.0

≤0.6

8.9-10

18-20

-

920℃

Normal conveyor use

304L

≤0.03

≤1.0

≤0.6

9-13

18-20

-

920℃

intercrystalline corrosion

316

≤0.08

≤1.0

≤0.6

10-14

16-18

2-3

920℃

Anti corrosion

316L

≤0.03

≤1.0

≤0.6

12-15

16-18

2-3

920℃

intercrystalline corrosion

309S

≤0.08

≤1.0

≤0.6

12-15

22-14

-

1000℃

Continuous high temperature

310s

≤0.08

≤1.5

≤0.6

19-22

24-26

-

1100℃

High temperature & heavy hit resisting

314

≤0.25

1.5-3.0

≤0.6

19-22

23-26

-

1200℃

Antioxidant plus all 310S

Cr20Ni80

≤0.15

0.4-1.3

≤0.6

72-78

20-23

-

1200℃

Antioxidant & high temperature resisting


Usual Tips:


Item name: Roller Conveyor Parts Roller Chain
Standard: ANSI B29.1 M­2002 (DIN 3183) and ISO 606.
Material: 40Mn, 45Mn,60Mn
Chain Type: Double pitch mid-hole pin chain
MOQ: Small order can be accepted
Delivery Time: Sample: Within 2-3days Production:15-20 days
Port of delivery: shenzhen/yantian
Payment Terms: T/T,L/C, Paypal ,Western Union,
Shipment: A. Send by Express – Swift delivery ( 4-7 working days) and we can get you a special price Shippment:UPS,TNT

,DHL,Chian post,EMS,FedEx ,etc.

B. Send by Air: Arrive at destination Airport.

C. Ship by Sea: Low shipping cost and slow delivery (15-30 days depends). Suitable for large quantity and

non-urgent delivery.

Packing Carton or wooden case, as your requirement
Supply Ability 200,000 pcs per month


Chain For Conveyor Belt

08bhp Chain

Industrial Chain

Driven Chain


There are so many types of roller chain for your different requirements,certain one of our products must be suitable for you.It is mainly divided into major applications:for wire mesh belt in spiral freezer conveyor and plate link beltSpiral Mesh Belts are suitable for the conveying of small and high density materials;Eye Link Belt is suited to convey heavy loads and unstable or fragile products that require good support from the conveyor belt. In a word,according to the use environment and clientsspecial requirements,we can be able to give them different type of roller chain.
